Samsung HPR8082X-XAA User Manual
Page 14
14
1
Remove the screws from the back panel of the main body of the PDP.
Fixing the PDP panel to the wall attachment panel bracket
The shape of the product may vary depending on the model. (The assemblies of the plastic
hanger and the screw are the same)
2
Fix the hinge to the back panel of the
PDP main body using the screws.
(8 Screws)
3
Hook the hinge on the wall mount.
PDP Main Body
Remove the 8 screws
Hinge
