General
General
Model Name SyncMaster 540B
LCD Panel
Size 15" Diagonal(38cm)
Display area 304.1mm (H) x 228.1mm (V)
Pixel Pitch 0.297mm (H) x 0.297mm (V)
Type a-si TFT active matrix
Synchronization
Horizontal 30 ~ 61 kHz
Vertical 56 ~ 75 Hz
Display Color
16.2M Colors
Resolution
Optimum resolution 1024 x 768@60 Hz
Maximum resolution 1024 x 768@75 Hz
Input Signal, Terminated
RGB Analog , DVI(Digital Visual Interface) Compliant Digital RGB
0.7Vp-p Positive at 75Ω +-10%
Separate H/V sync, Composite sync, SOG(Option), TTL level positive or negative.
Maximum Pixel Clock
81 MHz
Power Supply
AC 100 to 240 VAC(+/- 10%) ,60/50Hz ± 3Hz
Signal Cable
15pin to 15pin D-sub cable, Detachable, 1.8m
DVI-D to DVI-D connector, Detachable, 2.0m (option)
Power Consumption
