ALIGNMENT AND ADJUSTMENTS
11
Demo Mode
- Demo mode is entered when the Eco Plus(WA456*)+Pre Soak/Pre Soak + Extra Rinse(WA422*/
WA400*) buttons are held down for five (5) seconds simultaneously in the power on state.
- When entering Demo mode, the buzzer rings three (3) times and “- - - -” is displayed on the 7
segment display and all other LEDs are turned off. (Initial Demo mode)
- Demo mode consists of WASH, SPIN and LED modes.
- If the Temp. button is pressed during the initial Demo mode, “USH”(“US”(WA422*/WA400*))
blinks on the 7 segment display and the washing machine enters WASH mode.
- If the Start/Pause button is pressed in WASH mode, the door is locked (Door Lock) and the motor
rotates left and right at 110 RPM in a 1.4sec on and 0.9sec off cycle.
- WASH mode continues up to five (5) minutes once started. After the five (5) minutes have
elapsed, “- - - -” is displayed on the 7 segment display and the initial Demo mode is maintained.
- If the Start/Pause button is pressed during a WASH mode operation, “- - - -” is displayed on the 7
segment display and the initial Demo mode is maintained.
- If the Spin button is pressed in the initial Demo mode, “SPn”(“SP”(WA422*/WA400*)) blinks on
the 7 segment display and the washing machine enters SPIN mode.
- If the Start/Pause button is pressed in the SPIN mode, the door is locked (Door Lock) and a spin
is operated at 1000 RPM (WA456*) / 800 RPM (WA422*/WA400*).
- SPIN mode continues up to four (4) minutes once started. After the four (4) minutes have
elapsed, “- - - -” is displayed on the 7 segment display and the initial Demo mode is maintained.
- If the Start/Pause button is pressed during a SPIN mode operation, “- - - -” is displayed on the 7
segment display and the initial Demo mode is maintained.
- If the Soil Level button is pressed in the initial Demo mode, “LED”(“LE”(WA422*/WA400*)) blinks
on the 7 segment display and the washing machine enters LED mode.
- If the Start/Pause button is pressed in LED mode, all LEDs are turned on. The LED mode
continues up to thirty (30) seconds once started. After the thirty (30) seconds have elapsed, “- - -
-” is displayed on the 7 segment display and the initial Demo mode is entered.
- If the Start/Pause button is pressed during an LED mode operation, “- - - -” is displayed on the 7
segment display and the initial Demo mode is entered.
To avoid risk of electrical shock, personal injury or death; disconnect power to washer
before servicing, unless testing requires power.
WARNING
Eco Plus(WA456*) + Pre Soak
Pre Soak + Extra Rinse(WA422*/WA400*)
3sec
While a cycle is not running
