86 _
Machine status and advanced setup
NETWORK SETUP
You may set up the network with the machine's touch screen. Before doing
that, you must have the information concerning the type of network
protocols and computer system you use. If you are not sure which setting to
use, contact your network administrator to configure this machine network.
1.
Press Machine Setup on the control panel.
2. Press Admin Setting. When the login message pops up, enter
password and press OK.
3. Press the Setup tab > Network Setup.
Speaker Volume This controls the sound when a fax actually starts
to transfer data. If this option is On, the machine
sounds from a fax starts until a fax finishes. With
Comm. the machine sounds only until the
communication is succeeded. No sound with Off
option.
Prefix Dial
This feature allows you to set a prefix of up to five
digits. This number will be dialed before any
automatic number is dialed. User may set this to
access a PABX a (example 9) or area code
number (example 02). When sending a fax, there
may be a job which has same recipient's number
in delay jobs. In this case, the machine can send
faxes to the same recipient in a batch.
Junk Fax Setup The machine does not accept faxes sent from
remote stations if their numbers are stored in the
memory as junk fax numbers. You can enter a
maximum of 10 junk fax numbers. Press Junk
Fax Setup
and Edit, then, enter the fax numer. If
you have set Caller ID enabled, you can browse
the last received fax numbers and select a fax
number from the list .
Ring Volume
This feature adjusts the ring volume. When you
select Off, the machine does not ring.
Dial Tone Volume When you press On Hook Dial to send a fax, you
can hear a specific tone. To adjust the tone
volume, you can use this feature. Value 1 is the
lowest volume. Use left/right arrows to adjust the
value.
Output Tray This feature lets you select the paper tray to use
for receiving a fax.
Toll Save Set the machine to send a fax in the toll save time
for saving. (See "Sending a fax in toll save
time" on page 68.)
Send Batch The machine asks you whether you want to add
the documents to the reserved delay fax, if the fax
number you have dialed is same as the delay fax
number. (See "Adding documents to a reserved
delay fax job" on page 68.)
Fax Forward
Settings You can forward a sent or received fax to other
destination by a fax or an email. (See "Forwarding
a received fax to other destination" on page 68.)
Fax Ending Sound
This setting selects whether the end fax tone is on
or off.
Set whether you turn on or off the sound of an end
of fax receiving. (See "Setting up the end Fax
tone" on page 69.)
Caller ID If you have set this option, the machine
remembers the last twenty fax numbers.
a.Private Automatic Branch Exchange
OPTION DESCRIPTION
OPTION DESCRIPTION
TCP/IP Protocol
Select appropriate protocol and configure
parameters to use the network environment.
There are lots of parameters to be set,
therefore, if you are not sure, leave as it is,
or consult the network administrator.
Apple Talk
Protocol For Macintosh network environments, select this
option. This option provides packet transmission
and routing functionality for networking.
Ethernet Speed
Configure the network transmission speed.
Clear Setting
Reverts the network settings to the default values.
802.1x
You can select the user authentication for network
communication.
For details information consult the network
administrator.
IPv6
Machine supports IPv6 addresses for network
printing and managements.
• IPv6 Activate: When you select On, the Host
Name
and Link-Local Address will
automatically be entered into the address field.
• DHCPv6 Configuration: If you have a
DHCPv6 server on your network, you can set
one of the option for default dynamic host
configuration.
• Routers: Use DHCPv6 only when
requested by a router.
• DHCPv6 Addresses: Always use DHCPv6
regardless of router request.
• DHCPv6 Off: Never use DHCPv6
regardless of router request.
