Setting Up _1
01
setting
u
P
ADJusting tHe FReezeR DRAweR LeVeL
1. Locate the height-adjuster ( 1 ) in the freezer drawer.
Unscrew the four Phillips screws (
) slightly to loosen the door.
2. Loosen the controller screw(
) with a Phillips
screwdriver.
3. Find the best level to align the door slope.
After adjustment, tighten the screws (
)&( ) in reverse order.
Example) The slope is about 2mm (0.08inch) as shown below.
- Rotate the Height Adjuster to +2.0 to reduce the door
slope.
Slope
Reference
plane
Freezer Drawer
Adjustment part
1
