Connecting to an Analog Amplifier
•
Please be sure to match the color coded input terminals and cable jacks.
The “AUDIO OUT” terminals cannot be
used for external speakers. You must
hook them up to an amplifier.
When an audio amplifier is connected
to the “AUDIO OUT” terminals:
Decrease the gain (volume) of the
audio amplifier, and adjust the volume
level with the volume control on the TV.
TV Rear Panel
