Specifications – Samsung LS19C45KBRV-GO User Manual
Page 89

89
Specifications
10
10 Specifications
Model Name
S24C450MW
S27C450B
Panel
Size
24 Inches (61 cm)
27.0 Inches (68 cm)
Display area
518.4 mm (H) x
324.0 mm (V)
20.4 Inches (H) x
12.8 Inches (V)
597.6 mm (H) x
336.15 mm(V)
22.8 Inches (H) x
13.2 Inches (V)
Pixel Pitch
0.270 mm (H) x
0.270 mm (V)
0.011 Inches (H) x
0.011 Inches (V)
0.31125 mm (H) x
0.31125 mm (V)
0.012 Inches (H) x
0.012 Inches (V)
Synchronization
Horizontal
Frequency
30 ~ 81 kHz
30 ~ 81 kHz
Vertical
Frequency
56 ~ 63 Hz
56 ~ 75 Hz
Display Color
16.7M
Resolution
Optimum
Resolution
1920x1200@60Hz
1920x1080@60Hz
Maximum
Resolution
1920x1200@60Hz
1920x1080@60Hz
Maximum Pixel Clock
154 MHz (Analog,Digital)
148 MHz (Analog,Digital)
Power Supply
This product uses 100 to 240V.
Refer to the label at the back of the product as the standard
voltage can vary in different countries.
Signal connectors
15pin-to-15pin D-sub cable, Detachable
DVI-D to DVI-D connector, Detachable
Dimensions (W x H
x D) / Weight
Without Stand
554.8 x 359.35 x 54.2 mm
21.8 x 14.1 x 2.1 Inches
639 x 378.1 x 56.7 mm
25.2 x 14.9 x 2.2 Inches
With Stand
MIN: 554.8 x 382.25 x 224.0
mm / 5.1 kg
21.8 x 15.1 x 8.8 Inches /
11.24 lbs
MAX: 554.8 x 512.25 x 224.0
mm / 5.1 kg
21.8 x 20.2 x 8.8 Inches /
11.24 lbs
MIN: 639 x 397.8 x 224.0 mm
/ 6.2 kg
25.2 x 15.7 x 8.8 Inches /
13.67 lbs
MAX: 639 x 527.8 x 224.0 mm
/ 6.2 kg
25.2 x 20.8 x 8.8 Inches /
13.67 lbs
