85

Specifications

10

10 Specifications

Model Name

S23C450B

S23C450M

S24C450BL

Panel

Size

23 Inches (58 cm)

23 Inches (58 cm)

23.6 Inches (59 cm)

Display

area

509.76 mm (H) x

286.74 mm (V)

20.1 Inches (H) x

11.3 Inches (V)

509.76 mm (H) x

286.74 mm (V)

20.1 Inches (H) x

11.3 Inches (V)

521.28 mm (H) x

293.22 mm (V)

20.5 Inches (H) x

11.5 Inches (V)

Pixel Pitch

0.2655 mm (H) x

0.2655 mm (V)

0.010 Inches (H) x

0.010 Inches (V)

0.2655 mm (H) x

0.2655 mm (V)

0.010 Inches (H) x

0.010 Inches (V)

0.2715 mm (H) x

0.2715 mm (V)

0.011 Inches (H) x

0.011 Inches (V)

Synchronization

Horizontal

Frequency

30 ~ 81 kHz

Vertical

Frequency

56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum

Resolution

1920x1080@60Hz

Maximum

Resolution

1920x1080@60Hz

Maximum Pixel Clock

148 MHz (Analog,Digital)

Power Supply

This product uses 100 to 240V.

Refer to the label at the back of the product as the standard voltage

can vary in different countries.

Signal connectors

15pin-to-15pin D-sub cable, Detachable

DVI-D to DVI-D connector, Detachable

Dimensions (W

x H x D) /

Weight

Without

Stand

542.9 x 321.4 x

55.4 mm

21.4 x 12.7 x 2.2

Inches

542.9 x 321.4 x

55.4 mm

21.4 x 12.7 x 2.2

Inches

554.6 x 330.5 x

55.45 mm

21.9 x 14.2 x 2.4

Inches

With Stand

MIN: 542.9 x 344.65

x 224.0 mm / 4.6 kg

21.4 x 13.6 x 8.8

Inches / 10.14 lbs

MAX: 542.9 x 474.65

x 224.0 mm / 4.6 kg

21.4 x 18.7 x 8.8

Inches / 10.14 lbs

MIN: 542.9 x 344.65

x 224.0 mm / 4.55 kg

21.4 x 13.6 x 8.8

Inches / 10.03 lbs

MAX: 542.9 x 474.65

x 224.0 mm / 4.55 kg

21.4 x 18.7 x 8.8

Inches / 10.03 lbs

MIN: 554.6 x 352.35

x 224.0 mm / 5.4 kg

21.8 x 13.9 x 8.8

Inches / 11.90 lbs

MAX: 554.6 x 482.35

x 224.0 mm / 5.4 kg

21.8 x 19.0 x 8.8

Inches / 11.90 lbs
