20
REMOVING THE REFRIGERATOR DOORS
3) Remove the door from the lower hinge ( ➅) by
lifting the door ( ➆).
4) Remove the lower hinge ( ➇) from the bracket
( ➈) by lifting the lower hinge (➇)
1) With the door closed, remove the upper hinge cover ( ➀) using a screwdriver
2) Remove the hinge screws (②) and the ground screw (③) counter-clockwise, and take off the upper
hinge (④) in the direction of the arrow (⑤). Be careful when removing the door to ensure that it does
not fall on you.
Removing the Refrigerator Door
