ENG-9
Setup
3 4 5 1 8
9
7 6
10
VIDEO SEL.
OPEN/CLOSE
2
S
E T U P
Description
Front Panel Controls
1. STANDBY/ON ( )
When STANDBY/ON is pressed on, the indicator goes out
and the player is turned on.
2. STANDBY Indikator
When the unit is first plugged in, the indicator lights.
3. DISC TRAY
Place the disc here.
4. OPEN/CLOSE ( )
Press to open and close the disc tray.
5. DISPLAY
Operation indicators are displayed here.
6. VIDEO SEL.
Press to change Video output mode (Progressive ON or
Progressive OFF).
7. STOP ( )
Stops disc play.
8. SKIP ( ) / SEARCH
Use to forward skip a scene or music.
9. SKIP ( ) / SEARCH
Use to reverse skip a scene or music.
10. PLAY/PAUSE ( )
Begin or pause disc play.
Front Panel Display
Total playing time/Displays various
messages concerning operations such
as PLAY, STOP, LOAD ...
NOdSC: No disc loaded.
OPEn: The disc tray is open.
LOAd: Player is loading disc information.
