Samsung LS23C45KDSV-GO - Manual (Page 30)

30
Connecting and Using a Source Device
2
2 Connecting and Using a Source Device
2.3 Connecting and Using a PC
2.3.1 Connecting to a PC
Do not connect the power cable before connecting all other cables.
Ensure you connect a source device first before connecting the power cable.

Select a connection method suitable for your PC.
Connecting parts may differ in different products.
Connection Using the D-SUB Cable (Analogue Type)
1
Connect the D-SUB cable to the [RGB IN] port on the back of the product and the RGB port on the
PC.
2
Connect the power cable to the product and power outlet. Turn on the power switch on the PC.
3
Press [ ] to change the input source to Analog .
Connection Using the DVI Cable
1
Connect the DVI cable to the [DVI IN] port on the back of the product and the DVI port on the PC.
2
Connect the power cable to the product and power outlet. Turn on the power switch on the PC.
3
Press [ ] to change the input source to DVI .
RGB IN
RGB IN
DVI IN
DVI IN
