ADC ML-78 - Manual (Page 25)

Telephone: (508) 678-9000 Fax: (508) 678-9447
25
Illus. No. Part No. Qty Description
1 150300 2 #10 x 1/2" Hex Washer TEK Screw
2 132083 1 Step Down Transformer (for 208/240 volts Only)
881763 Termination Kit
3 150301 2 #8-18 x 7/16" Phillips Pan Head TEK Screw
4 136008 2 Fuse Holder ONLY
5 136057 2 1/2 Amp (Slo Blo) Fuse
6 150297 1 #10 x 1/2" Hex Washer TEK Screw - green
7 121010 1 L-70 Ground Lug
8 153002 1 5/16" Lock Washer
9 152004 1 5/16-18 Hex Nut
10 137015 1 RC Network
11 132447 1 3-Pole Contactor - 24 VAC
12 322812 1 Electric Relay Panel Mounting Plate ONLY
13 150008 2 #6-32 x 1-1/4" Phillips Round Head Machine Screw
14 120701 1 4-Position Terminal Block
15 151000 2 #6-32 Pal Nut
16 121300 3 Open/Closed Bushing
3-Phase Motor, Non-Reversing Electric Relay Panel Assembly
