Single phase motor, electric relay panel assembly – ADC ML-78 User Manual
Page 23
Telephone: (508) 678-9000
Fax: (508) 678-9447
23
Illus. No.
Part No.
Qty
Description
1
137015
1
RC Network
2
151000
2
#6-32 Pal Nut
3
150300
2
#10 x 1/2" Hex Washer TEK Screw
4
150008
2
#6-32 x 1 1/4" Phillips Round Head Machine Screw
5
120716
1
2 Position Terminal Block
6
306304
1
Electric Relay Panel Mounting Plate ONLY
7
132083
1
Step Down Transformer (for 120/240 Volt 1Ø Only)
881763
1
Termination kit
8
136008
*
Fuse Holder ONLY
9
136049
1
3/4 Amp (Slo Blo) Fuse (for 120 Volt Models Only)
136057
2
1/2 amp (Slo Blo) fuse (for 208/240 Volt Only)
10
150301
*
#8-18 x 7/16" Phillips Pan Head TEK Screw
11
150297
1
#10 x 1/2" Hex Washer TEK Screw - Green
12
152004
1
5/16-18 Hex Nut
13
121010
1
L-70 Ground Lug
14
153002
1
5/16" Lock Washer
15
132445
1
3-Pole Contactor - 24 VAC
16
121300
3
Open/Closed Bushing
* As Required
Single Phase Motor, Electric Relay Panel Assembly
