88
Specifications
10
10 Specifications
10.4 PC Dongle Specification (UWB : Ultra Wide Band)
Standard UWB
Host Interface USB 2.0 Downstream Interface
Frequency Range 3.1GHz ~ 10.6Ghz (Operating 3.16GHz ~ 8.97Ghz, BG1, BG2, BG6)
Security AES128
Data Rate 53.3 to 480 Mbps
Sensitivity / Output Power Transmitted signal PSD -41.3 dBm/MHz
(Regulatory limit is -41.3dBm/Mhz)
Power Consumption 1.18Watt (Typical), Receiving 4095 length packet, TFC1, Band Group 3,
480 Mbps.
Supported Models C24A650X, C27A650X, C24A650U, C27A650U, C23A750X, C27A750X
Dimension 7 mm x 19 mm x 24.5 mm
