Dimensions

• Port panel detail / Rear view

3

4

2

5

1

(Unit: inches)

The displayed image may differ depending on the model.

Model name

1

2

3

4

5

UN46F7500

15.7

15.7

12.5

2.9

4.6

UN55F7500

15.7

15.7

16.3

6.5

5.2

UN60F7500

15.7

15.7

16.3

6.5

5.2

NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior
notice. Refer to the dimensions before installing your TV. Not responsible for typographical or printed errors.
