Samsung LS19C45KBRV-GO - Manual (Page 83)

83
Specifications
10
10 Specifications
Model Name S22C450M S22C450BW S22C450MW
Panel
Size 54 cm 55 cm 55 cm
Display
area
476.64 mm (H) x
268.11 mm (V)
473.76 mm (H) x
296.1 mm (V)
473.76 mm (H) x
296.1 mm (V)
Pixel Pitch
0.24825 mm (H) x
0.24825 mm (V)
0.282 mm (H) x
0.282 mm (V)
0.282 mm (H) x
0.282 mm (V)
Synchronization
Horizontal
Frequency
30 ~ 81 kHz
Vertical
Frequency
56 ~ 75 Hz
Display Color 16.7M
Resolution
Optimum
Resolution
1920x1080@60Hz 1680x1050@60Hz
Maximum
Resolution
1920x1080@60Hz 1680x1050@60Hz
Maximum Pixel Clock
148 MHz
(Analog,Digital)
146 MHz (Analog,Digital)
Power Supply
This product uses 100 to 240V.
Refer to the label at the back of the product as the standard voltage
can vary in different countries.
Signal connectors
15pin-to-15pin D-sub cable, Detachable
DVI-D to DVI-D connector, Detachable
Dimensions (W
x H x D) /
Weight
Without
Stand
504.3 x 301.9 x
55.45 mm
502.4 x 329.8 x
55.5 mm
502.4 x 329.8 x
55.5 mm
With Stand
MIN:504.3 x 325.35 x
210 mm / 4.5 kg
MAX:504.3 x 425.35
x 210 mm / 4.5 kg
MIN:502.4 x 353.5 x
210 mm / 5.0 kg
MAX:502.4 x 453.5 x
210 mm / 5.0 kg
MIN:502.4 x 353.5 x
210 mm / 5.0 kg
MAX:502.4 x 453.5 x
210 mm / 5.0 kg
VESA Mounting Interface
100 mm x 100 mm
(For use with Specialty(Arm) Mounting hardware.)
Environmental
considerations
Operating
Temperature : 10°C – 40°C (50°F – 104°F)
Humidity : 10 % – 80 %, non-condensing
Storage
Temperature : -20°C – 45°C (-4°F – 113°F)
Humidity : 5 % – 95 %, non-condensing
