Page 20

20
REMOVING THE REFRIGERATOR DOORS
3) Remove the door from the lower hinge (
➅) by
lifting the door (
➆).
4) Remove the lower hinge (
➇) from the bracket
(
➈) by lifting the lower hinge (➇)
1) With the door closed, remove the upper hinge cover (
➀) using a screwdriver
2) Remove hinge screws (②) and ground screw (③) counter-clockwise, and take off the upper hinge
(④) in the direction of the arrow (⑤). Be careful when removing the door to ensure that it does not
fall on you.
Removing the Refrigerator Door
DA99-01278A(0.4)EN1
