Samsung LF19BKBLB-ZA - Manual (Page 71)

Specifications
General
General
Model Name SyncMaster 930ND
LCD Panel
Size 19 diagonal (48 cm)
Display area 376.32 mm (H) x 301.05 mm (V)
Pixel Pitch 0.294 mm (H) x 0.294 mm (W)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16.7 M
Resolution
Optimum resolution 1280x1024@60 Hz (RB)
Maximum resolution 1280x1024@60 Hz (RB)
Input Signal, Terminated
RGB Analog
0.7 Vp-p ±5 %
Separate H/V sync, Composite
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
135 MHz(Analog)
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin-to-15pin D-sub cable, Detachable
Dimensions (W x H x D) / Weight
416.6 x 420.9 x 200 mm / 16.4 x 16.6 x 7.9 inch (With Stand)/ 6.9 kg / 15.2 Ibs
416.6 x 375.2 x 74.7 mm / 16.4 x 16.6 x 7.9 inch (Without Stand)
VESA Mounting Interface
100 x 100 mm
