General
General
Model Name SyncMaster 940MW
LCD Panel
Size 19.0 inch diagonal (48 cm)
Display area 408.24 mm(H) x 255.15 mm(V)
Pixel Pitch 0.2835 mm(H) x 0.2835 mm(V)
Synchronization
Horizontal 30 ~ 61 kHz
Vertical 56 ~ 75 Hz
Display Color
16.7 M Colors
Resolution
Optimum resolution WXGA+ 1440 x 900 @ 60 Hz
Maximum resolution WXGA+ 1440 x 900 @ 60 Hz
Input Signal, Terminated
RGB Analog, DVI(Digital Visual Interface)
Composite Digital RGB, 0.7Vp-p±5%, Positive bright, 75Ω±10%(terminated),
Separate H/V sync, Composite,TTL level, positive or negative
TV / Video
Color system NTSC-M, PAL-M/N, PAL/SECAM - L/L',B/G,D/K,I
Video format S-Video, Composite, Component, Built-in-Tuner, PIP
Maximum Pixel Clock
81 MHz
Power Supply
AC 100 ~ 240 VAC (+/- 10%), 60/50 Hz ± 3 Hz
Signal Cable
15pin to 15pin D-sub cable, Detachable
DVI-D to DVI-D connector, Detachable (Option)
