16 Specifications
16
Specifications
16.1 General (S19C150N / S22C150N)
Model Name S19C150N S22C150N
Panel Size 18.5 Inches (47 cm) 21.5 Inches (54 cm)
Display area 409.8 mm (H) x 230.4 mm (V)
16.1 Inches (H) x 9.1 Inches (V)
476.64 mm (H) x 268.11 mm (V)
18.8 Inches (H) x 10.6 Inches (V)
Pixel Pitch 0.300 mm (H) x 0.300 mm (V)
0.012 Inches (H) x 0.012 Inches (V)
0.24825 mm (H) x 0.24825 mm (V)
0.01 Inches (H) x 0.01 Inches (V)
Synchronization Horizontal
Frequency
30 ~ 81 kHz
Vertical
Frequency
56 ~ 75 Hz
Display Color 16.7 M
Resolution Optimum
Resolution
1366 x 768 @ 60 Hz 1920 x 1080 @ 60 Hz
Maximum
Resolution
1366 x 768 @ 60 Hz 1920 x 1080 @ 60 Hz
Input Signal, Terminated RGB Analog
0.7 Vp-p ± 5%
separate H/V sync, Composite, SOG
TTL level (V high ≥ 2.0V, V low ≤ 0.8V)
Maximum Pixel Clock 85 MHz (Analog) 148 MHz (Analog)
Power Supply This product supports 100-240 V. Since the standard voltage may
differ from country to country, please check the label on the back of
the product.
Signal connectors 15pin-to-15pin D-sub cable, Detachable
Dimensions
(W x H x D) / Weight
Without
Stand
445 x 273 x 53 mm
17.5 x 10.7 x 2.1 Inches
512 x 311 x 53 mm
20.2 x 12.2 x 2.1 Inches
With Stand 445 x 348 x 177 mm / 2.15 kg
17.5 x 13.7 x 7.0 Inches / 4.7 lbs
512 x 385 x 197 mm / 3.1 kg
20.2 x 15.2 x 7.8 Inches / 6.8 lbs
Environmental
considerations
Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)
Humidity : 10 % – 80 %, non-condensing
Storage Temperature : -4°F ~ 113°F (-20°C ~ 45°C)
Humidity : 5 % – 95 %, non-condensing
