Samsung RS267LASH-XAA - Manual (Page 18)

18
REMOVING THE REFRIGERATOR DOORS
1) Remove the screw from clamp ( ).
2) Remove the water tube by pressing the coupler ( ➁) and pulling the water tube (➀) away.
Open the freezer and refrigerator doors, and then take off the front leg cover by turning the
three screws counter-clockwise.
a
a
FRONT LEG COVER
SCREW
Removing the Front Leg Cover
Separating the Water Supply Line from the Refrigerator
Do not cut the water tube. Separate it from the coupler.
NOTE
DA68-01506C(0.1)EN-1 2006.5.6 11:45 AM 페이지18
