Applications
• Scaling of profitable ATM, frame
relay and private-line services
at lower cost
• Addition of new revenue-
generating Ethernet/IP services
using cost-effective multiservice
capabilities
• Interworking and convergence
of multiservice traffic in core
Layer-2 multiservice networks
Protocol Support
AT M
• UNI 3.0/3.1/4.0/4.1
• Traffic management 4.1
• IISP
• PNNI 1.1, H-PNNI
• B-ICI
• IMA 1.0/1.1
• Resilient UNI
• Fast APS
• APS trunk backup
• PVC redirect
F R A M E R E L AY
• FRF.5/FRF.8 ATM network/service
interworking
• FRF.16.1 Multilink frame relay
• Subrate DS3
• RFC 1490 Translation FRAD
• UNI (DTE/DCE)
• NNI
• Priority frame
• SVCs
• LMI
• FRF.12/.13/.18/.19
E T H E R N E T / I P / M P L S
• BGP-4
• OSPF
• RIP
• Static
• IGMP
• RFC 2917 PPP
• PoS
• MP-iBGP
• OSPF-TE
• RSVP-TE
• LDP
• PWE3 encapsulation
• 10/100 Mb/s/Gigabit Ethernet
• VLAN (2 levels)
• Service interworking of Ethernet
with frame relay/ATM over
MPLS/ATM core
• Ethernet-to-ATM interworking
(VC/VLAN mapping)
• RFC 2684 Ethernet-to-frame
relay interworking bridged mode
• RFC 2684/IEEE 802.3 Ethernet-
like MIB
• ATM and Ethernet pseudowires
(PWE3)
Interface Modules
U N I V E R S A L I / O ( AT M , P O S, G I G E )
• 24-port DS3 ATM IOA
• 1-port OC-48c/STM-16 ATM/PoS
IOA
• 16-port OC-3c/STM-1 ATM IOA
• 2-port GigE (R10)
• 4-port OC-12c/STM-4 ATM/PoS
IOA
AT M I / O
• 4-port OC-3/STM-1 ATM*
• 8-port DS3 ATM*
• 1-port Ch. STM-1/E1 ATM with
IMA*
• 3-port Ch. DS3/1 ATM with IMA*
• 60-port Ch. T1/E1 circuit
emulation*
F R A M E R E L AY / I P / E T H E R N E T I / O
• 6-port Ch. DS3/1/0 frame relay
with MFR*
• 32-port E1 frame relay with MFR*
• 8-port DS3 subrate frame relay*
• 4-port 10/100 Ethernet*
*Module shared with Alcatel-Lucent
CBX 500 Multiservice WAN Switch
System Architecture
• 35 Gb/s full-duplex switching
capacity
• 16 slots
• Distributed routing and signaling
• Redundant processors, modules,
fans, timing, power
• Priority-based circuit routing
• Multimode LED-based interfaces
Network Synchronization
• External/internal Stratum 3 timing
• Line timing
• Loop timing
• Holdover
• Free-running
Operations, Administration
and Maintenance
• Internal, external and line
loopback
• Alarm and trap monitoring
• Path trace
• F4/F5 OAM cells (loopback)
MXOS™ Multiservice Switch
Operating Software
Carrier-grade, hardened software
provides superior switch reliability
and network scalability.
Network Management
• End-to-end Layer-2 provisioning
via provisioning manager
• Fault correlation via fault
manager
• Performance data and reports
• Billing and SLA management
Physical Dimensions
• Height: 80.0 cm (31.5 in.)
• Width: 48.3 cm (19.0 in.)
• Depth: 48.3 cm (19.0 in.)
• Weight: under 90.7 kg (200.0 lb)
fully configured
• Rack-mount options: EIA 48.3 cm
(19 in.) or 58.4 cm (23.0 in.)
mid-mount, CO style
Power
• Redundant-chassis power distri -
bution system
• 120 V AC to 240 V AC (requires
external converter)
• –48 V DC with dual power feeds;
max. 60 A
• Current:
¬ 20 A max. (120 V AC)
¬ 60 A max. (–48 V DC)
• Thermal dissipation: max. 2,880 W
Operating Environment
• Temperature: 0 C to 50 C
(32 F to 122 F)
Regulatory Compliance
E N V I R O N M E N TA L / N E B S
• GR-63-CORE
• GR-1089-CORE
S A F E T Y
• UL 1950/CSA 22.2 950 (U.S.A.,
Canada)
• CAS 9590
E M C
• FCC Part 15, Class A (U.S.A.)
• EN 55022 Class A (Europe)
T E C H N I C A L S P E C I F I C A T I O N S
