REMOVING THE REFRIGERATOR DOORS
3) Remove the door from the lower hinge (
➆
) by
lifting the door (
➇
).
4) Remove the lower hinge (
➈
) from the bracket
lower hinge (
➉
) by lifting the lower hinge (
➈
) in
the direction of the arrow.
1) With the door closed, remove the upper hinge cover (
➀
) using a screwdriver, and then disconnect
the wires (
➁
).
2) Remove hinge screws (
➂
) and ground screw (
➃
) counter-clockwise, and take off the upper hinge
(
➄
) in the direction of the arrow (
➅
). Take care when removing the door to ensure that it does not fall
on you.
Removing the Refrigerator Door
