25

-EN

& Left Rear (+) Speaker Output Lead (Green)

(CDA-7864/CDA-7863/CDA-7862 only)

( Left Rear (–) Speaker Output Lead (Green/

Black) (CDA-7864/CDA-7863/CDA-7862 only)

) Left Front (–) Speaker Output Lead (White/

Black) (CDA-7864/CDA-7863/CDA-7862 only)

~ Left Front (+) Speaker Output Lead (White)

(CDA-7864/CDA-7863/CDA-7862 only)

+ Ai-NET Connector

Connect this to the output or input connector of other
product (CD Changer, Equalizer, etc.) equipped with
Ai-NET.

NOTE

You can input TV/video sound by connecting an optional
Ai-NET/RCA Interface cable (KCA-121B) to this
component.

, DC/DC Converter (CDA-7965 only)

NOTES

Do not install the converter at a location subjected to

water such as under the floor mat or air conditioner.
This may cause a malfunction.

Do not bundle the DC/DC converter cable with other

audio cables. Doing so may induce noise into your
system.

- Ai-NET Cable (Included with CD Changer)
. Front Output RCA Connectors
/ Rear Output RCA Connectors (CDA-7965 only)

RED is right and WHITE is left.

: Subwoofer RCA Connectors (CDA-7965 only)

RED is right and WHITE is left.

; Rear/Subwoofer Output RCA Connectors

(CDA-7864/CDA-7863/CDA-7862 only)
RED is right and WHITE is left.

< RCA Extension Cable (Sold Separately)
= System Switch

When connecting an equalizer or divider using Ai-
NET feature, place this switch in the EQ/DIV
position. When no device is connected, leave the
switch in the NORM position.

NOTE

Be sure to turn the power off to the unit before changing
the switch position.

1 Antenna Receptacle
2 Power Antenna Lead (Blue)

Connect this lead to the +B terminal of your power
antenna, if applicable.

3 Remote Turn-On Lead (Blue/White)

Connect this lead to the remote turn-on lead of your
amplifier or signal processor.

4 Audio Interrupt In Lead (Pink/Black)
5 Illumination Lead (Orange)

This lead may be connected to the vehicle's
instrument cluster illumination lead. This will allow
the backlighting of the CDA-7965/CDA-7864/CDA-
7863/CDA-7862 to dim whenever the vehicle's lights
are turned on.

6 Switched Power Lead (Ignition) (Red)

Connect this lead to an open terminal on the vehicle's
fuse box or another unused power source which
provides (+)12V only when the ignition is turned on
or in the accessory position.

7 Battery Lead (Yellow)

Connect this lead to the positive (+) post of the
vehicle's battery.

NOTE(CDA-7864/CDA-7863 only)

Use an extension battery lead (20A)(sold separately) and
connect it directly to the positive (+) side of the vehicle's
battery.

8 Ground Lead (Black)

Connect this lead to a good chassis ground on the
vehicle. Make sure the connection is made to bare
metal and is securely fastened using the sheet metal
screw provided.

9 Fuse Holder

(5A ...... CDA-7965 only)

(20A .... CDA-7864/CDA-7863 only)

(15A .... CDA-7862 only)

! Power Supply Connector
" Right Front (+) Speaker Output Lead (Gray)

(CDA-7864/CDA-7863/CDA-7862 only)

# Right Front (–) Speaker Output Lead (Gray/

Black) (CDA-7864/CDA-7863/CDA-7862 only)

$ Right Rear (–) Speaker Output Lead (Violet/

Black) (CDA-7864/CDA-7863/CDA-7862 only)

% Right Rear (+) Speaker Output Lead (Violet)

(CDA-7864/CDA-7863/CDA-7862 only)

To prevent external noise from entering the audio system.
• Locate the unit and route the leads at least 10 cm away from the car harness.

• Keep the battery power leads as far away from other leads as possible.

• Connect the ground lead securely to a bare metal spot (remove the coating if necessary) of the car chassis.

• If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries

various Alpine noise suppressors, contact them for further information.

• Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.
