22
REATTACHING THE REFRIGERATOR DOORS
Reattaching the Refrigerator Door
1) Insert the lower hinge ( ➀) into the lower hinge
bracket ( ➁).
2) Place the hole in the refrigerator door ( ➂) over
the lower hinge ( ➃).
3) Insert the upper hinge shaft ( ➄) into the hole (➅). After levelling between the upper hinge hole (➆) and
the hole of the cabinet ( ➇). Reattach hinge screws (➈) and gound screw (➉) in the clockwise direction.
9
10
4) Put the front part of the upper hinge cover ( ) on the front part of the upper hinge ( ) and reattach it
from the front part of the upper hinge cover first.
11 12
