B. COMPONENT IDENTIFICATION
1. Dryer Front View
Illus. No.
Description
1
Microprocessor Control/Keyboard (Touchpad) Panel Assembly (Controls)
2
Control (Top Access) Door Assembly
3
Main Door Assembly
4
Lint Door Assembly
5
Lint Drawer
6
EMERGENCY STOP (E-Stop) Button
7
Wire Diagram (located behind Control Door)
8
Top Console (Module) Assembly
