Introduction
6
NI-2000, NI-3000, NI-4000 Hardware Reference Guide
NI-3000 Specifications
The front LEDs (FIG. 3) are grouped by control type and are labeled according to their corresponding
port (connector) numbers on the rear of the unit. The back of the this unit contains RS-232/422/485,
Relay, IR/Serial and I/O connectors. In addition, this unit provides an ID pushbutton, AXlink LED, and
other related connectors. FIG. 4 shows the front and rear of the
NI-3000.
FIG. 3
NI-3000 NetLinx Integrated Controller (front view)
FIG. 4
NI-3000 front and rear panel components
AXlink LED
Relays
RS-232/422/485 (Ports 1-7)
I/O (Port 17)
IR/Serial (Ports 9-16)
Front
Rear
Program
DIP
switch
ICSNet (2)
ICSHub Out
(green)
ID Pushbutton
(Port 8)
Ethernet
AXlink
port
PWR
RS-232/422/485 TX/RX LEDs (red/yellow)
Relay LEDs (red)
IR/Serial LEDs (red)
I/O LEDs (yellow)
port
Link/Active-Status-Output-Input
