WARNING: THIS SPEAKER IS CAPABLE OF PRODUCING
SOUND PRESSURE LEVELS (SPL) WHICH CAN CAUSE
HEARING IMPAIRMENTS OR LOSS. EAR PROTECTION
IS RECOMMENDED
IMPEDANCE: 4 OHMS
POWER: 500W RMS/1000 PEAK
I N P U T S
PIN 1+ = POS(+)
PIN 1- = NEG(-)
-db
LEVEL CONTROL
4
5
6
7
8
8
9
10
11
12
16 0
1
2
3
Heritage Bass Guitar Cabinets
SVT-410HLF / SVT-810E
6
SVT-410HLF Jackplate
Speakon
®
to 1/4” Wiring Diagram:
1+
1-
1+ 1-
1 2 3
1: 1/4” Input / Output Jacks
2: Speakon
® Input / Output Jacks
3: High Frequency Horn Level Control
