Transaxle Maintenance and Repair (cont’d)
Pack Mule Transaxle Parts List
#
Part
Part Number
QTY
3
Gear, Input
See Kit
1
4
Ring, Retaining
EV-T016
3
5
O-Ring
EV-T014
3
6
Bearing, Ball
EV-T015
1
7
Bearing, Ball
EV-T013
1
8
Plug, End Cap
EV-T017
2
9
Bearing, Ball
EV-T011
2
10
Gear, Intermediate Assembly
See Kit
1
11
O-Ring
EV-T010
2
12
Gear, Final Drive
See Kit
13
Bearing, Ball
EV-T008
2
15
Screw, Cap
EV-T006
4
16
Nut, Lock
EV-T007
4
17
Plate, Cover
EV-T018
1
18
Plug, Fill
EV-T020
1
19
Screw, Cover Plate
EV-T021
10
23
Brake Assembly, Left Hand Shoe Type
EV-T054
1
23
Brake Assembly, Left Hand Shoe Type (Stock Chaser)
EV-T054-S
1
24
Brake Assembly, Right Hand Shoe Type
EV-T055
1
24
Brake Assembly, Right Hand Shoe Type (Stock Chaser)
EV-T055-S
1
25
Shaft, Axle 29˝ Left Hand (15 1/4˝ length)
EV-T023-29
1
25
Shaft, Axle 32˝ Left Hand (18 1/8˝ length)
EV-T023-32
1
25
Shaft, Axle 36˝ Left Hand (23 1/4˝ length)
EV-T023-36
1
26
Shaft, Axle Right Hand
EV-T025
1
28
Seal, Oil
EV-T030
2
29
Ring, Retaining
EV-T029
4
30
Bearing, Ball
EV-T028
2
31, 32, 33
Hub and Drum – 4-lug assembly with studs
EV-T058
2
34
Nut, Flange Hex
EV-T064
2
Kit
Kit, Gear Set (Includes #3, #10, #12)
EV-T065
1
