Campbell Scientific LI190SB LI-COR Quantum Sensor - Manual (Page 6)

LI190SB Quantum Sensor
2. Specifications
Stability: < ±2% change over a 1 year period
Response Time: 10 μs
Temperature
Dependence:
0.15% per °C maximum
Cosine Correction: Cosine corrected up to 80 ° angle of incidence
Operating
Temperature:
-40 to 65 °C
Relative Humidity: 0 to 100%
Detector: High stability silicon photovoltaic detector (blue
enhanced)
Sensor Housing: Weatherproof anodized aluminum case with acrylic
diffuser and stainless steel hardware
Size: 0.94” dia x 1.00” H (2.38 x 2.54 cm);
Weight: 1 oz. (28 g)
Calibration: ±5% traceable to the U.S. National Institute of
Standards Technology (NIST)
Sensitivity: Typically 5 μA per 1000 μmoles s -1 m -2
Linearity: Maximum deviation of 1% up to 10,000 μmoles s -1 m -2
Shunt Resistor: 604 ohms
Light Spectrum
Waveband:
400 to 700 nm
The black outer jacket of the cable is Santoprene ® rubber. This NOTE
compound was chosen for its resistance to temperature extremes,
moisture, and UV degradation. However, this jacket will
support combustion in air. It is rated as slow burning when
tested according to U.L. 94 H.B. and will pass FMVSS302.
Local fire codes may preclude its use inside buildings.
LI-COR
QUANTUM
Q
1 7 9 9 2
FIGURE 2-1. LI190SB Quantum Sensor
2
