IRTS-P Precision Infrared Temperature Sensor

*Table 2 Program
02: 0.0000 Execution

Interval

(seconds)

*Table 3 Subroutines

End Program

-Input Locations-
1 RefTemp 1 2 1
2 AppTargT 1 2 1
3 SenBodyT 1 3 1
4 Psb 1 3 3
5 Hsb 1 4 3
6 Ksb 1 2 2
7 SEC 1 1 1
8 CTT 1 0 1

CR23X Example Program

;{CR23X}
;
*Table 1 Program
01: 1

Execution

Interval

(seconds)

;Measure Panel Reference Temperature

1: Panel Temperature (P17)
1: 1

Loc [ RefTemp ]

;Measure IRt/c apparent target temperature

2: Thermocouple Temp (DIFF) (P14)
1: 1

Reps

2: 21

10 mV, 60 Hz Reject, Slow Range

3: 1

DIFF

Channel

4: 3

Type

(Chromel-Alumel)

5: 1

Ref Temp (Deg. C) Loc [ RefTemp ]

6: 2

Loc

[

AppTargT

]

7: 1.0

Mult

8: 0.0

Offset

;Measure Sensor Body Temp

3: Thermocouple Temp (DIFF) (P14)
1: 1
