CURS100 100 Ohm Current Shunt Terminal Input Module
10
BeginProg
Scan (1,Sec,1,0)
'Generic 4-20 mA Input measurement Measure:
VoltDiff
(Measure,1,mV2500,1,True,0,_60Hz,0.0625,-25.0)
CallTable
(Hourly)
NextScan
EndProg
5.4 CR9000(X) Program Example
VoltDiff(Press_psi, 1, mV5000, 5, 1, 1, 0, 0, 0.3125, 75)
5.5 CR10(X) Program Example
1: Volt (Diff) (P2)
1:
1
Reps
2:
25
± 2500 mV 60 Hz Rejection Range
3:
1
DIFF
Channel
4:
1
Loc [ Press_psi ]
5:
0.3125 Mult
6:
75
Offset
5.6 CR23X Program Example
1: Volt (Diff) (P2)
1:
1
Reps
2:
25
± 5000 mV, 60 Hz Reject, Fast Range
3:
1
DIFF
Channel
4:
1
Loc [ Press_psi ]
5:
0.3125 Mult
6:
75
Offset
