27106T Gill Propeller Anemometer
Dimensions
Overall Length: 17 inch (43 cm)
Propeller Diameter: 8 inch (20 cm)
Housing Diameter: 1 inch (2.5 cm)
1180 Mounting Pipe Description: 12-in. long, 3/4-in. IPS schedule 40 pipe
(1.05 in. OD)
Weight: 1.2 lbs (0.5 kg)
*Threshold and Distant Constant values are for axial flows.
Manufactured by RM Young (Traverse City, MI) and cabled by Campbell
Scientific for use with our dataloggers.
The black outer jacket of the cable is Santoprene ® rubber. This
compound was chosen for its resistance to temperature extremes,
moisture, and UV degradation. However, this jacket will
support combustion in air. It is rated as slow burning when
tested according to U.L. 94 H.B. and will pass FMVSS302.
Local fire codes may preclude its use inside buildings.
NOTE
3. Installation
3.1 Unpack Equipment and Assemble the 27106T
Upon receipt of your shipment, immediately open the shipping carton and
ensure that you have all of the 27106T’s components.
The shipping carton should include:
• 16” x 2” x 2” box labeled Propeller Anemometer
• 9” x 9” x 2” box labeled Carbon Fiber Propeller
• Cable (routed through the 1180 mounting pipe to mating connector)
• 1180 Mounting Pipe
Make sure that you have removed everything (two boxes,
cable, and mounting pipe) from the shipping carton before
discarding the shipping foam and shipping carton. Foam
included with the shipping carton may conceal items. If an
item listed above is not initially visible, remove the foam
from the shipping carton and thoroughly inspect both sides
of the foam for the item. Immediately contact Campbell
Scientific if any item is missing. CAUTION
2
