RIM-Protocol Converter User Guide - Version 1.0
24
www.chatsworth.com
Once setup, each device’s status is color coded.
Figure 3.6 Protocol Converter Color Codes
Note: The color codes are also available in the Help section of the Protocol Converter interface.
Click on an individual device number to view individual information being polled from that
device to the Protocol Converter.
Figure 3.7 Register Status Example
Device #1: I/O Module
