• Battery voltage indicator “BATTERY”
This bar chart controls a light that will move up and down as the battery voltage changes. Ideally, the voltage should
remain in the green area of the bar chart.
If the voltage goes into the red area at the top and bottom of the graph, inverter may shut down.
• Output power indicator “OUTPUT (%) POWER”
The AC load watt chart indicates the power drawn from the inverter by the load. Ideally, the watt indicator should remain
in the green & orange area of the bar chart.
If the OUTPUT POWER indicator is up to the red area of the bar, the light will flash and the inverter will shut down for
inverter safety.
• Over voltage protection indicator “OVP”
The over voltage protection indicator is to indicate that the inverter has shut down because its input voltage is above 12 /
24 VDC.
• Under voltage protection indicator “UVP”
The under voltage protection indicator is to indicate that the inverter has shut down because its input voltage is below 12
/ 24 VDC.
• Over temperature protection indicator “OTP”
The over temperature protection indicator is to indicate that the inverter has shut down because of overheating. The over
temp indicator will be OFF when the inverter cools down.
• Overload protection indicator “OLP”
The overload protection indicator is to indicate that the inverter has shut down because of short circuit or overload
problems.
• “INV” indicator
The INV indicator is to indicate that the inverter is ready.
• GRID indicator
The GRID indicator is to indicate that the inverter is in Pass Through Mode & transferring Grid power to the load
(Applicable to the versions with Transfer Relay).
• PWR.SAV. Indicator
Power saving functions are described below:
LED Meaning Inverter Output
Solid Ready ON
Flashing Active OFF
Off Inactive
