2-2. Electrical Characteristics
Model BP-1210A BP-1205A BP-2405A BP-2403A
Output
DC Voltage Range 14.4V 14.4V 28.8V 28.8V
Rated Current 10A 5A 5A 2.5A
Current Range 0 ~ 10A 0 ~ 5A 0 ~ 5A 0 ~ 2.5A
Rated Power (max.) 144W 72W 144W 72W
Battery Charger Mode 3 - stage Battery Chargers ( Refer to Battery Charging Curve)
Indication LED Refer to LED Status
Input
Voltage Range 88 ~ 264VAC
Frequency Range 47Hz ~ 63Hz
Efficiency ( Typ. ) at 230Vac 80% 78% 83% 80%
AC Current ( Max. ) 1.9 A / 90VAC 0.95A / 180VAC
Inrush Current ( Typ. ) Cold Start 30A / 230VAC
Leakage Current < 0.75mA / 240VAC
Protection
Over Load
102~110% rated output power
Protection type : Consta nt current lim iting, Hiccup m ode, recovers a utomatically
after fault condition is removed
Over Temperature
85°C ± 5°C ( TH1 ) detect on heat sink
Protection type : Shut d own output voltage, recovers automatically after
temperature goes down
Environment
Working Temp. - 20°C ~ 50°C
Working Humidity 20 ~ 90% RH non-condensing
Storage Temp., Humidity - 40 ~ +85°C
Temp.Coefficient ± 0.03% / °C ( 0 ~ 50°C )
Vibration 10 ~ 500Hz, 1G 0.5Oct/min, period for 60min. Each along X,Y,Z axes
Safety
&
EMC
Safety Standards IEC 60950-1, 1st Edition ( 2001 ) ; EN 60950-1, 1st Edition ( 2001+A11 )
Withstand Voltage I/P - O/P:3KVAC I/P - FG:1.5KVAC O/P-FG:0.5KVAC, 1 minute
Isolation Resistance I/P - O/P, I/P - FG, O/P - FG:100M Ohms/500VDC
EMI Conduction & Radiation EN 55022 : 2006 Class B
Harmonic Current
EN 61000-3-2 : 2006 ; EN 61000-3-3 :1995+A1 : 2001+A2 : 2005 ;
EN 55024 : 1998+A1:2001+A2 : 2003 ;
EMS Immunity
IEC 61000-4-2 Edition 1.2 : 2001 -04 ; IEC 6100 0-4-4 : 2004
IEC 61000-4-5 Edition 1.1 : 2001-0 4 ; IEC 6100 0-4-6 Edition 2.1 : 2004-1 1
IEC 61000-4-8 Edition 1.1 : 2001-03 ; IEC 61000-4-11 Second Edition : 2004-03
Others
MTBF
Compliance: MIL-HDBK-217F
Dimension (L*W*H) (mm)
210 (L) x 85 (W) x 50 (H) mm / 8.26 (L) x 3.34 (W) x 1.96 (H) Inch
Packing 1 kg. / 2.2 Lbs.
Note
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of
ambient temperature.
2. The power supply is considered a component which will be installed into a final equipment.
3. The final equipment must be re-confirmed that it still meets EMC directives.
*Note : The specifications are subject to change without notice.
