Battery to inverter cable connection, Battery – Samlex America SK User Manual
Page 21
PORT
CHASSIS
GROUND
REMOTE
NEG(-)
POS(+)
DC INPUT
INLINE FUSE
SK1000
SK700
SK1500
SK2000
SK3000
INLINE FUSE
REVERSE POLARITY
WILL DAMAGE UNIT
SHOCK HAZARD.
DO NOT OPEN. NO
USER SERVICEABLE
PARTS INSIDE.
WARNING:
DC INPUT
POS(+)
CHASSIS
GROUND
NEG(-)
REMOTE
PORT
Battery to inverter cable connection
Do not place anything between
battery cable lug and terminal surface.
Assemble exactly as shown.
19
BATTERY
BATTERY
M8 NUT
SPRING WASHER
RING TERMINAL
PVC WIRE
WASHER
PLASTIC COVER
(BLACK)
PLASTIC COVER
(RED)
