4 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 5
seCtIOn 1 | safety Instructions
the 12V battery version and 33.0 VDC for the 24V battery version to prevent permanent
damage to the unit. Please observe the following precautions:
• Ensure that the maximum charging voltage of the external battery charger / alterna-
tor / solar charge controller does not exceed 16.5 VDC for the 12V battery version and
33.0 VDC for the 24V battery version
• Do not use unregulated solar panels to charge the battery connected to this unit.
Under cold ambient temperatures, the output of the solar panel may reach > 22 VDC
for 12V Battery System and > 44 VDC for the 24V Battery system. Always use a charge
controller between the solar panel and the battery.
• Do not connect this unit to a battery system with a voltage higher than the rated bat-
tery input voltage of the unit (e.g. do not connect the 12V version of the unit to 24V
battery system or the 24V version to the 48V Battery System)
Preventing Reverse Polarity on the input Side
When making battery connections on the input side, make sure that the polarity of bat-
tery connections is correct (Connect the Positive of the battery to the Positive terminal
of the unit and the Negative of the battery to the Negative terminal of the unit). If the
input is connected in reverse polarity, DC fuse(s) inside the inverter will blow and may
also cause permanent damage to the inverter.
!
cAUtion!
Damage caused by reverse polarity is not covered by warranty.
Using Hard Wiring Ac output connections in Vehicles
WARninG!
RiSK oF eLectRic SHocK
When this unit is installed in vehicles and hard-wiring connection is used to
feed the AC output of the inverter to the AC Distribution Panel / Load Center in
the vehicle, it is to be ensured that Ground fault Circuit Interrupter(s) [GfCI]are
installed in the vehicle wiring system to protect all branch circuits.
The following GfCIs have been tested to operate satisfactorily and are accept-
able. other types may fail to operate properly when connected to this inverter:
Manufacturer
of GFci
Manufacturer's
Model no.
Description
Pass & Seymour 2095 Series NEMA5-20 Duplex, 20A
Leviton 7899 Series NEMA5-20 Duplex, 20A
Zhejiang Trimone TGM20 Series NEMA5-20 Duplex, 20A
