42 | SAMLEX AMERICA INC.
seCtIOn 12 | specifications
MoDeL no. PSt-1500-12 PSt-1500-24
oUtPUt
oUTPUT VoLTAGE 120 VAC ± 3% 120 VAC ± 3%
MAXIMUM oUTPUT CURRENT 12.5A 12.5A
oUTPUT fREQUENCY 60 Hz ± 1% 60 Hz ± 1%
TYPE of oUTPUT WAVEfoRM Pure Sine Wave Pure Sine Wave
ToTAL HARMoNIC DISToRTIoN of
oUTPUT WAVEfoRM
< 3% < 3%
CoNTINUoUS oUTPUT PoWER (At Power factor = 1) 1500 Watts 1500 Watts
SURGE oUTPUT PoWER (At Power factor = 1; <1 sec) 3000 Watts 3000 Watts
PEAK EffICIENCY (At full load) 85% 85%
AC oUTPUT CoNNECTIoNS
(i) NEMA5-20R GfCI Duplex Receptacle (ii) Terminal
block for hardwiring: Hole diameter (4 mm / 0.16")
& Set Screw (#6 x 40TPI or M3.5 x 0.6 mm Pitch)
inPUt
NoMINAL DC INPUT VoLTAGE 12V 24V
DC INPUT VoLTAGE RANGE 10.7 - 16.5 VDC 21.4 - 33 VDC
MAXIMUM INPUT CURRENT 200A 100A
DC INPUT CURRENT AT No LoAD 1.0A 0.8A
DC INPUT CoNNECTIoNS Bolt & nut: 5/16" x 18 TPI
DC INPUT fUSES (INTERNAL)
5 X 40A = 200A
(Each Type ATC, 32V, 40A)
5 x 20A = 100A
(Each Type ATC, 32V, 20A)
LeD DiSPLAY Power, overload, over Temperature
PRotectionS
LoW DC INPUT VoLTAGE ALARM 10.7V 21.4V
LoW DC INPUT VoLTAGE SHUTDoWN 10V 20V
HIGH DC INPUT VoLTAGE SHUTDoWN 16.5V 33V
SHoRT CIRCUIT SHUTDoWN Yes Yes
oVERLoAD SHUTDoWN Yes Yes
GRoUND fAULT SHUTDoWN Yes Yes
oVER TEMPERATURE SHUTDoWN Yes Yes
REVERSE PoLARITY oN DC INPUT SIDE Yes Yes
WiReD ReMote contRoL (oPtionAL) RC-200 (Sold separately)
FoRceD AiR cooLinG 2 Temperature Controlled fans
coMPLiAnce
SAfETY
Intertek - ETL Listed. Conforms to ANSI/UL
Standard 458.
EMI / EMC fCC Part 15(B), Class B
enViRonMent
oPERATING TEMPERATURE RANGE 32°f to 104°f / 0 to 40˚C
DiMenSionS AnD WeiGHtS
(L X W X H), MM 468.2 x 263 x 105.6 468.2 x 263 x 105.6
(L X W X H), INCHES 18.43 x 10.35 x 4.16 18.43 x 10.35 x 4.16
KG 7.1 7.1
LBS 15.6 15.6
See Specification Table Cautions (page 43)
