6 | SAMLEX AMERICA INC.
SECTION 4 |
INSTALLATION
Please refer to fig. 1. The Remote Control can be flush mounted on a wall or a
panel by making a suitable cut-out to accommodate the projection in the back.
Connect one end of the cable set to the RJ-50 Modular Jack (7) at the back and
the Remote and the other end to the RJ-50 Modular Jack on the inverter. ensure
that the connection is firm and the tab on the plug securely locks in the jack.
SECTION 5 |
OPERATION
Please refer to fig 1. Please also refer to the owner’s Manual of the inverter
for associated details. NOTE:
For the Remote Control to operate, the ON/OFF Switch
on the inverter is required to be in ON condition to activate the control circuitry for the
Remote Control. Switch on the inverter first with the help of the Power ON/OFF Switch on
the inverter. The output of the inverter can now be switched OFF/ON by pressing the ON/
OFF Push Button (1).
See under headings “LCD Display” and “LeD Display” above for information
on the operating conditions. Read the owner’s Manual of the inverter for
troubleshooting of abnormal conditions indicated by the LeDs.
No Load Current Draw
As stated above, the oN/off Switch on the inverter is required to be in oN
condition for the Remote to operate. When the oN/off switch on the Remote
Control is turned oN, all the circuitry inside the inverter becomes fully alive and
the AC output is made available. In this condition, even when no load is being
supplied (or, if a load is connected but has been switched off), the inverter
draws a small amount of current from the batteries to keep the circuitry alive
and is ready to deliver the required power on demand. This is called the “idle
current” or the “no load current draw”. When the inverter is turned off using
this Remote Control, some control circuitry is still alive in the inverter and will
require very small current draw. Hence, when the load is not required to be
operated, turn off the oN/off Switch on the inverter to prevent unnecessary
current drain from the battery.
SECTION 6 |
SPECIFICATIONS
MoDeL NuMbeRS of
CoMPATIbLe INVeRTeRS
PST-1500-12, PST-1500-24
PST-2000-12, PST-2000-24
CAbLe SeT
RJ-50 (10P10C) with crossed-over / rolled-
over connections. Length = 5 metres /16.5'
oPeRATING TeMPeRATuRe RANGe
0 to 40°C / 32°f to 104°f
DIMeNSIoNS (L x W x D)
110 x 65 x 24.7 mm / 4.33 x 2.56 x 0.97 in
Weight (Without cable / with cable)
85 gm / 256 gm; 0.04 lb / 0.12 lb
NOTE: Specifications are subject to change without notice
