6


1. MIC1 \ MIC2 \ MIC3 \ MIC4
MIC volume control (MIC1/MIC2/MIC3/MIC4)
2. AUX
AUX volume control
3. BASS
Adjust bass response. Rotate clockwise to increase
bass output and anticlockwise to reduce it.
4. TREBLE
Adjust treble response. Rotate clockwise to increase
treble output and anticlockwise to reduce it.
5. MASTER

control

6. POWER SWITCH
On top of the opening Power
Press the end, power shut down

Master volume

4. NOMENCLATURE AND FUNCTIONS

1

7. ON
Protection indicator
8. OUTPUT LEVEL

9. TAPE
Select tape channel input

keyswitch

10.CD
Select CD channel input keyswitch
11.TUNER
Select tuner channel input keyswitch
12.LINE
Select line channel input keyswitch

Power level indicator

2

6

4.1 FRONT PANEL

4

5

3

7

8

9

10

11

12

Project60/Project120

PROJECT

60

TAPE

CD

TUNER

LINE

MIC 1

MIC 2

MIC 3

MIC 4

BASS

TREBLE

AUX

MASTER

OUTPUT LEVEL

POWER

0

-12

+12

0

-12

+12
