6-2 85032B/E
Replaceable Parts
Introduction
Introduction
Table 6-1 lists the replacement part numbers for items included in the 85032B calibration
kit and Figure 6-1 illustrates each of these items.
Table 6-2 lists the replacement part numbers for items included in the 85032E calibration
kit and Figure 6-2 illustrates each of these items.
Table 6-3 lists the replacement part numbers for items recommended or required for
successful operation but not included in the calibration kit.
To order a listed part, note the description, the part number, and the quantity desired.
Telephone or send your order to Agilent Technologies. See
Table 5-1 on page 5-3 .
Table 6-1 Replaceable Parts for the 85032B Calibration Kit
Item No. Description Qty Per Kit Agilent Part Number
Calibration Devices (50 Ω Type-N)
1 Male broadband load 1 00909-60009
2 Female broadband load 1 00909-60010
3 Male short 1 85032-60008
4 Female short 1 85032-60009
5 Male open 1 85032-60007
6
Female open
a
a. Includes center conductor extender.
1 85032-60012
Adapters (included with Option 100)
b
b. Refer to “Options” on page 1-3 for description of available options.
7 Type-N-male to 7-mm 2 85054-60009
8 Type-N-female to 7-mm 2 85054-60001
Calibration Kit Storage Case
9 Box assembly (includes case and foam pad set) 1 85032-60010
10 Case (without foam pad set) c
c. Included in box assembly.
1 85032-80002
11
Foam pad set
c 1 85032-80003
Protective End Caps for Connectors
12 Female end cap for type-N as required 1401-0225
13 Male end cap for type-N and 7 mm as required 1401-0214
Miscellaneous Items
15 User’s and service guide 1 85032-90020
