85032B/E 2-5
Specifications
Electrical Specifications
Electrical Specifications
The electrical specifications in Table 2-3 apply to the devices in your calibration kit when
connected with an Agilent precision interface.
Certification
Agilent Technologies certifies that this product met its published specifications at the time
of shipment from the factory. Agilent further certifies that its calibration measurements
are traceable to the United States National Institute of Standards and Technology (NIST)
to the extent allowed by the institute’s calibration facility, and to the calibration facilities
of other International Standards Organization members. See
“How Agilent Verifies the
Devices in This Kit” on page 4-2 for more information.
Supplemental Electrical Characteristics
Supplemental electrical characteristics are values which are typically met by a majority of
the calibration kit devices tested. These supplemental characteristics are intended to
provide information in calibration kit applications by giving typical, but non-warranted,
performance parameters.
Table 2-4 lists the typical electrical characteristics of the 50
Ω
loads and adapters in the 85032B/E calibration kit.
Table 2-3 Electrical Specifications for 50
Ω
Type-N Devices
Device Specification Frequency (GHz)
Loads Return loss
≥
49 dB
(ρ ≤
0.00355) DC to
≤
2
Return loss
≥
46 dB
(ρ ≤
0.00501) > 2 to
≤
3
Return loss
≥
40 dB
(ρ ≤
0.01000) > 3 to
≤
6
Female open a
a. The specifications for the opens and shorts are given as allowed deviation from the nominal
model as defined in the standard definitions. See Table A-3 on page A-5 .
±
0.501
° ±
0.484
°/
GHz deviation from nominal DC to
≤
6
Female short
a
±
0.490
° ±
0.385
°/
GHz deviation from nominal DC to
≤
6
Male open
a
±
0.501
° ±
0.234
°/
GHz deviation from nominal DC to
≤
6
Male short
a
±
0.441
° ±
0.444
°/
GHz deviation from nominal DC to
≤
6
Adapters (type-N to 7-mm) Return loss
≥ 30
d
Β (ρ ≤
0.03162) DC to
≤
6
Table 2-4 Supplemental Electrical Characteristics
Device Specification Frequency (GHz)
Loads Return loss
≥ 23
d
Β (ρ ≤
0.07079) > 6 to
≤
18
Adapters (type-N to 7-mm) Return loss ≥ 34 d Β (ρ ≤ 0.01995) DC to ≤ 8
Return loss
≥ 28
d
Β (ρ ≤
0.03981) > 8 to
≤
18
