Table 7: 8 Byte Map
MSB LSB
* * * 1 2 3 4 5 Data Byte 1
* * * 6 7 8 9 10 Data Byte 2
* * * 11 12 13 14 15 Data Byte 3
* * * 16 17 18 19 20 Data Byte 4
* * * 21 22 23 24 25 Data Byte 5
* * * 26 27 28 29 30 Data Byte 6
* * * 31 32 33 34 35 Data Byte 7
* * * 36 37 38 39 40 Data Byte 8
A "1" bit indicates an on (black) pixel, a "0" bit indicates an off (clear) pixel.
Once defined, a character is displayed simply by issuing a value (0x00 to 0x07) corresponding to the
character number. The character will be laid out as follows;
Table 8: Character Values
1 2 3 4 5
6 7 8 9 10
11 12 13 14 15
16 17 18 19 20
21 22 23 24 25
26 27 28 29 30
31 32 33 34 35
36 37 38 39 40
Cursor Line
NOTE Custom characters will be erased if any of the "Initialize bar graph" commands
are issued.
5.1.7 Initialize large digits (254 110)
This command defines the 8 special / user characters to be blocks suitable for use in drawing large digits.
Any previously existing definitions will be lost. Once this command has been issued, any number of large
characters may be placed until the characters are redefined by another command.
