Description This command will load the narrow vertical bar characters into the
volatile memory. If you have stored your own custom vertical bar data,
use the ’Load Custom Characters’ command instead to load your
custom bar data into the volatile memory. This command will allow you
to use the ’Place Vertical Bar’ command.
NOTE Narrow bars have a width of two pixels.
Remembered No
6.11 Initialize Wide Vertical Bar
Syntax Hexadecimal 0xFE 0x76
Decimal 254 118
ASCII 254 “v”
Description This command will load the wide vertical bar characters into the volatile
memory. If you have stored your own custom vertical bar data, use the
’Load Custom Characters’ command instead to load your custom bar
data into the volatile memory. This command will allow you to use the
’Place Vertical Bar’ command.
NOTE Wide bars have a width of five pixels.
Remembered No
6.12 Place Vertical Bar
Syntax Hexadecimal 0xFE 0x3D [Column] [Length]
Decimal 254 61 [Column] [Length]
ASCII 254 “=” [Column] [Length]
Parameters Parameter Length Description
Column 1 The column number.
Length 1 The length of the bar data.
Matrix Orbital LK402-25 26
