9 Appendix: Specifications and Options
9.1 Specifications
Table 30: Environmental Specifications
Standard Temperature Extended Temperature
Operating Temperature 0 ◦ C to +50 ◦ C -20 ◦ C to +70 ◦ C
Storage Temperature -20 ◦ C to +70 ◦ C -40 ◦ C to +85 ◦ C
Operating Relative Humidity 20 to 80% non condensing
Vibration (non-operating) 10 to 55 to 10 Hz (Frequency)
1.0 mm (Total Amplitudes)
30 minutes (Duration)
X, Y, Z each direction
Shock (Non-operation) 593 m/S 2 , 10 mS
Table 31: Electrical Specifications
Supply Voltage 4.75 - 5.25 Vdc (optional 8 - 15 VDC)
Supply Current 9 mA typical
Supply Backlight Current 115 mA typical
Table 32: Optical Characteristics
Number of Characters 40 (20 characters by 2 lines)
Matrix Format 5 x 7 with underline
Display Area 82.2 x 18.20 mm XxY
Character Size 2.4 x 4.7 mm (XxY), not including
underline
Character Pitch 3.55 mm
Line Pitch 5.35 mm
Dot Size 0.55 x 0.55 mm (XxY)
Dot Pitch 0.6 x 0.6 mm (XxY)
LED Backlight Life 100,000 hours typical
Color of Illumination Yellow Green, Ice Blue, Inverse
Red, Inverse Yellow and Inverse
Blue
