16.4 Ordering Information()
G L K 122 32 -25 -SM -WB -V -E
1 2 3 4 5 6 7 8 9 10
Table 84: Part Numbering Scheme
# Description Options
1 Screen Type G: Graphic
2 Display Technology L: Liquid Crystal Display
3 Input Interface K: Keypad
4 Width 122: Pixel Width Count
5 Height 32: Pixel Height Count
6 Keypad Buttons -25: External 25 Key Input Maximum
7 Form Factor -SM: Small
8 Colour (Text/Background) NP: Standard (Grey/White)
-WB: White/Blue
9 Input Voltage NP: Standard (4.75-5.25V)
-V: Extended Voltage (9.00-15.0V)
10 Temperature NP: Standard (0 ◦ C to +50 ◦ C)
-E: Extended Temperature (-20 ◦ C to +70 ◦ C)
Table 85: Part Options
16.5 Definitions
E Extended Temperature (-20C to 70C)
V Wide Voltage (+9 to +15Vdc)
GW Grey Text / White Background
WB White Text / Blue Background
MSB Most Significant Byte
LSB Least Significant Byte
16.6 Contacting Matrix Orbital
Telephone
Matrix Orbital GLK12232-25-SM 64
