Hardware Information
Refer to the following diagram for this chapter:
Figure 10: GLK12232-25-SM
Table 1: Hardware information
1
Power/Data Connector
5
Protocol Select Jumpers
2
Floppy Power Connector
6
Filesystem Lock Jumper
3
Keypad Interface Connector
7
Manual Override
4
GPO
2.1
Power/Data Connector
Matrix Orbital
GLK12232-25-SM
6
