9
*Flow rates are stated for Nitrogen at STP conditions [i.e. 70 F F (21.1 F C) at 1 atm].
For other gases use the K factor as a multiplier from APPENDIX 2.
CODE scc/min [N
2
] CODE std liters/min [N
2
]
00 0 to 5 07 0 to 1
01 0 to 10 08 0 to 2
02 0 to 20 09 0 to 5
03 0 to 50 10 0 to 10
04 0 to 100
05 0 to 200
06 0 to 500
TABLE I XFM 17 LOW FLOW MASS FLOW METER*
TABLE II XFM 37 MEDIUM FLOW MASS FLOW METER*
FLOW RANGES
CODE std liters/min [N
2
]
30 20
31 30
32 40
33 50
TABLE III XFM XFM 47/57/67/77 HIGH FLOW MASS FLOW METERS*
CODE std liters/min [N
2
]
40 60
41 80
42 100
50 200
60 500
70 1000
