MULTI-TASKER
8
the command [VERC2U3]. T he Multi-Tasker™
will return the following feedback:
MT104-107 690-0160-002
MT104-107 = card type
690-0160-002 = software version
2. [C]
This command receives the status of the card.
Command Format: [CnUi]
Cn = card ID (n = 1 to max slots)
Ui = unit id (i = from 0 to 9)
Example:
There is an MT104-107 card is in slot #2 of
unit 3. S-Video Input 1 is ON and C -Video
Input 3 is ON. To get the status of the card,
send the command
[C2U3] . The feedback will
be as follows:
ON: 1-SVID 3-CVID
1-SVID = S-Video Input 1 ON
3-CVID = Composite Video Input 3 ON
If there is no card in slot #2 of unit 3, sending
the
[C2U3] command will not return any
feedback.
3. [CnS]
This command saves the current status of the
card's input to output configuration. This
configuration will be restored after the system is
Reset or powered OFF then ON.
Cn = card number
S
= save configuration
If S-Video Outputs 1,2,3 and Video Outputs
1,2,3 are enabled, the feedback after sending
the command [C4S], for slot 4, would be:
SVID: 1,2,3 CVID: 1,2,3 C04 Saved
4. [ON]
This command enables one input of a single
card or a group of cards.
SINGLE CARD
[ONmVCnUiS] for Composite Video
[ONmSCnUiS] for S-Video
This command enables input “m” and disables
all other inputs.
[ONmVCnUi]: Enables one composite video
input (C-Video)
[ONmSCnUi]: Enables one S-Video input
Default when plugged in:
S-Video Input #1 = ON
C-Video Input #1 = ON
m = Input number (m = 1 to 4)
(input 4 is internal)
Cn = Card ID (n = # from 1 to max slots)
Ui
= Unit ID number (i = 0 to 9)
S = activates S-Video input
V = activates C-Video input
S = saves command to memory
Example:
All of the inputs on the MT104-107 card are
OFF and the card is in slot #5 of unit 3:
1) [ON1VC5U3] : Turns ON C-Video input 1.
2) [ON3VC5U3] : Turns ON C-Video input 3
Since only one of each input type may be
selected at a time, Input 1 is now OFF. It
was turned OFF automatically when Input 3
was turned ON.
3) [ON2SC5U3] : Turns ON S-Video input 2.
GROUP OF CARDS
[ONmVGkUiS] for Composite Video
[ONmSGkUiS] for S-Video
This command enables input "m" for each card
in group "k" of unit "i".
[ONmVGkUi]: Enables a group of composite
video inputs (C-Video)
[ONmSGkUi]: Enables a group of S -Video
inputs
m = Input number (m = 1 to 4)
(input 4 is internal)
Gk =
group number (k = # from 1-9)
Ui = unit number (i = # from 0-9)
S = activates S-Video input
V = activates C-Video input
